Description

Stainless Steel Carbine Snap Hooks Din5299 Form C-China LG™

The Stainless Steel Carbine Snap Hooks Din5299 Form C from China LG™ are durable and versatile tools designed for a wide range of lifting, pulling, and securing tasks. This set features a 3/8″ thick Pear Ring, a 3/8″ Grab Hook, and an 18″ chain with a Pear Ring attached to a 14″ chain and Grab Hook. These Chain Anchors, each featuring a Pear Ring and Grab Hook, are well-suited for use with engine cranes, load binders, and other equipment that require secure connections. Crafted from heavy-duty steel and zinc-plated to prevent rust and corrosion, the Grab Hook with 18″ Chain Anchor Pear Ring offered by China LG™ delivers exceptional durability and reliability in challenging work environments. The Stainless Steel Carbine Snap Hooks Din5299 Form C-China LG™ are a versatile and durable option for a variety of applications. These hooks are commonly used in the food and beverage industry due to their high-quality finish that meets industry standards. The spring-loaded gate allows for quick and easy attachment and removal of items, making them ideal for hanging cords, ropes, hoses, and more. Whether you need a handle for carrying items or a hanger for storage, these carabiner hooks offer dozens of practical uses around the home, RV, or boat. Made from stainless steel, these hooks are built to last and are resistant to rust, high temperatures, and corrosion. This makes them suitable for use in environments with exposure to dust, chemicals, or salt water. Overall, the Stainless Steel Carbine Snap Hooks Din5299 Form C-China LG™ are a reliable and convenient solution for a wide range of everyday needs.

Technical& Application

Technical Notes	Conform to DIN5299 Form C
Material	Stainless Steel AISI 316 or AISI 304
Processing	Stamping / Machining
Surface Finished	Highly Polishing / Electrophoretic coating
Size	4mm , 5mm , 6mm , 7mm , 8mm , 9mm , 10mm , 11mm , 12mm , 13mm , 14mm
Tips	Not for overhead lifting
Brand	LG™
Origin	China

Specification -Stainless Steel Carbine Snap Hooks Din5299 Form C

Part No.	Size(mm)	D(mm)	A(mm)	C(mm)	D1(mm)	WLL(lbs)
LG-SS-SH5299C-04	4×40	4	40	6	6.5	80
LG-SS-SH5299C-05	5×50	5	50	7	8	100
LG-SS-SH5299C-06	6×60	6	60	8	9	140
LG-SS-SH5299C-07	7×70	7	70	8	10.5	200
LG-SS-SH5299C-08	8×80	8	80	9	12	250
LG-SS-SH5299C-09	9×90	9	90	10	13	280
LG-SS-SH5299C-10	10×100	10	100	12	15	400
LG-SS-SH5299C-11	11×120	11	120	16	18	500
LG-SS-SH5299C-12	12×140	12	140	19	20	600
LG-SS-SH5299C-13	13×160	13	160	25	22	700
LG-SS-SH5299C-14	14×180	14	180	35	22	900
