Grade 80 Alloy Bolt Type Anchor Bow Shackles-China LG™
China LG™ is pleased to introduce the Grade 80 Alloy Bolt Type Anchor Bow Shackles, a top-of-the-line hardware solution that offers exceptional strength and reliability for a variety of rigging and lifting applications. Also referred to as Grade 80 safety pin bow shackles, these shackles are specifically designed to provide secure connections and support in demanding environments. The Grade 80 Alloy Bolt Type Anchor Bow Shackles are ideal for safeguarding lifting slings from potential damage caused by cutting or abrasion, ensuring the longevity and safety of your lifting operations. The anchor bow style of these shackles allows for versatile use, accommodating loads or pulls from multiple angles with ease and efficiency. Commonly utilized in lifting applications across industries such as marine, agricultural, mining, and engineering, these shackles are essential components for connecting chains, wire ropes, and other rated fittings securely. Their robust construction and high-quality materials guarantee reliable performance under heavy loads and harsh conditions. Crafted using premium-grade raw materials in accordance with stringent international quality standards, the Grade 80 Alloy Bolt Type Anchor Bow Shackles from China LG™ are built to withstand the rigors of heavy-duty lifting tasks. Whether you require standard sizes or customized options, our range of safety pin bow shackles can be tailored to meet your specific project needs, ensuring optimal performance and safety. For a trusted and durable solution for your rigging and lifting requirements, rely on the Grade 80 Alloy Bolt Type Anchor Bow Shackles from China LG™ to deliver unmatched strength and performance in every application. Grade80 Alloy Bolt Type Anchor Bow Shackles is an excellent lifting cable protection device that can effectively prevent damage due to cutting or wear. Its anchor bow style can adapt to multiple angles of load or tension. The safety anchor chain hook introduced in our country has two options: standard size and customized size, to meet the needs of different occasions. The design concept of this G80 alloy bolt type anchor chain hook is to prioritize safety and practicality. Made of high-strength alloy materials, it remains sturdy and durable even under heavy loads. In addition, its unique anchor bow shape allows it to maintain stability under multiple angles of load and tension, greatly improving its efficiency of use. Overall, Grade80 Alloy Bolt Type Anchor Bow Shackles is a highly cost-effective lifting cable protection device. Its excellent performance and wide range of application scenarios make it a popular product in the Chinese market. Whether you are looking for standard or customized sizes of anchor chain hooks, our LG company can provide you with satisfactory products and services.Technical & Application
| Grade | 80 |
| Technical Notes | U.S. Federal Specification |
| Safety Factor | 5 : 1 |
| Material | Super Alloy Steel |
| Processing | Drop Forged / Quenched and Tempered |
| Finish | Body : Hot Dipped Galvanized Pin : Powder Coating |
| Size | 5/16” , 3/8” , 7/16” , 1/2” , 5/8” , 3/4” , 7/8” , 1” , 1-1/8” , 1-1/4” , 1-3/8” , 1-1/2” , 1-3/4” , 2” |
| Tips | Special specification and marks can be made according to customers’ requirements |
Specification-Grade 80 Alloy Bolt Type Anchor Bow Shackles
| Part No. | Size | WLL/T | B.L/T | A±1.5 | C±1.5 | D±1 | L±3 | N | L1±3 | B | N.W./LBS |
| LG-8-AS+B-5/16 | 5/16″ | 1.2 | 6 | 13.5 | 21.3 | 8 | 53 | 9.5 | 50.5 | 8.4 | 0.22 |
| LG-8-AS+B-3/8 | 3/8″ | 1.6 | 8 | 16.8 | 25.9 | 9.7 | 63.2 | 11 | 62 | 10.8 | 0.33 |
| LG-8-AS+B-7/16 | 7/16″ | 2.5 | 12.5 | 19 | 29.5 | 11.2 | 74 | 13 | 70 | 12.8 | 0.49 |
| LG-8-AS+B-1/2 | 1/2″ | 3.3 | 16.5 | 20.6 | 33.3 | 12.7 | 83.3 | 16 | 79.5 | 14.8 | 1.01 |
| LG-8-AS+B-5/8 | 5/8″ | 5 | 25 | 27 | 42.9 | 17.5 | 106.4 | 19 | 101.5 | 18 | 1.6 |
| LG-8-AS+B-3/4 | 3/4″ | 7 | 35 | 32 | 50.8 | 20.6 | 126.2 | 22 | 117.5 | 19.4 | 2.42 |
| LG-8-AS+B-7/8 | 7/8″ | 9.5 | 47.5 | 36.6 | 57.9 | 24.6 | 148 | 25 | 136 | 21.5 | 3.95 |
| LG-8-AS+B-1/1 | 1″ | 12.5 | 62.5 | 43 | 68.3 | 27 | 166.6 | 28 | 153.5 | 23.8 | 5.66 |
| LG-8-AS+B-1-1/8 | 1-1/8″ | 15 | 75 | 46 | 74 | 31.75 | 190 | 32 | 171.5 | 25.6 | 8.27 |
| LG-8-AS+B-1-1/4 | 1-1/4″ | 18 | 90 | 51.6 | 82.5 | 35 | 210 | 35 | 192 | 31 | 11.71 |
| LG-8-AS+B-1-3/8 | 1-3/8″ | 21 | 105 | 57 | 92 | 36 | 232.7 | 38 | 202 | 33.4 | 15.83 |
| LG-8-AS+B-1-1/2 | 1-1/2″ | 30 | 150 | 60.5 | 98 | 41 | 254 | 42 | 222 | 34 | 20.8 |
| LG-8-AS+B-1-3/4 | 1-3/4″ | 40 | 200 | 73.2 | 126 | 57.2 | 313.7 | 51 | 278 | 38 | 33.91 |
| LG-8-AS+B-2/1 | 2″ | 55 | 275 | 82.5 | 146 | 61 | 347.5 | 57 | 307 | 45 | 52.25 |
