Description
G80 Forged Pear Shaped Link-China LG Manufacture
The G80 Forged Pear Shaped Link manufactured by China LG is a versatile and robust component that is essential for a wide range of lifting and rigging applications. This pear-shaped link is meticulously crafted with precision and attention to detail, ensuring superior quality and performance that meets the stringent standards set by China LG Manufacture. Made from Grade 80 alloy steel, the G80 Forged Pear Shaped Link offers exceptional strength and durability, making it suitable for heavy-duty lifting tasks. Its forged construction enhances its load-bearing capacity, allowing it to withstand high loads and tough working conditions with ease. The pear-shaped design of this link provides a secure connection point for chains, ropes, and other lifting accessories. Whether used for hoisting materials, securing loads, or towing applications, the G80 Forged Pear Shaped Link ensures a reliable and safe connection that enhances the efficiency and safety of lifting operations. Versatile and easy to use, this link is suitable for various industries, including construction, maritime, logistics, and more. Its high-quality construction and reliable performance make it a trusted choice for professionals in the lifting and rigging industry.G80 Forged Pear Shaped Link Description
The G80 Forged Pear Shaped Link, manufactured by China LG, stands out as a robust and reliable component in lifting operations. Crafted from forged super alloy steel and meticulously quenched and tempered, this link ensures superior strength and durability in demanding environments. Each G80 Pear Shaped Link Weldless undergoes rigorous individual proof testing at 2.5 times its Working Load Limit, guaranteeing safety and performance under heavy loads. With its high fatigue resistance, the Grade 80 Pear Shaped Link Weldless excels in enduring repetitive stress, making it an ideal choice for a wide range of lifting applications where reliability is paramount, particularly when used as a Master Link. While these Pear Shaped Links can be employed for similar tasks as oblong master links, their design may not be optimized for multiple branch slings. Additionally, in certain situations, there is a possibility of interference with crane hooks. Careful consideration of these factors is essential to ensure safe and efficient lifting operations.Technical & Application
| Technical Notes | US Federal Specification |
| Material | Superior Alloy steel |
| Processing | Drop Forged |
| Surface Finished | Powder Coated |
| Size | 3/8” , 1/2” , 5/8” , 3/4” , 7/8” , 1” , 1-1/4” , 1-3/8” , 1-1/2” , 1-3/4” , 2” |
| Safety Factor | 5:1 |
| Tips | G80 components.Suitable for use with G80 chain. |
Specification – G80 Forged Pear Shaped Link
| Part No. | Diameter | Inside Length | Inside Width | Each Weight | W.L.L (Single Pull) | |
| Small end | Large end | Alloy | ||||
| Alloy | inch | inch | inch | inch | lbs | lbs |
| LG-PL-3/8 | 3/8” | 2.25 | 0.75 | 1.5 | 0.23 | * |
| LG-PL-1/2 | 1/2” | 3 | 1 | 2 | 0.55 | 7000 |
| LG-PL-5/8 | 5/8” | 3.75 | 1.25 | 2.5 | 1.1 | 9000 |
| LG-PL-3/4 | 3/4” | 4.5 | 1.5 | 3 | 1.95 | 12300 |
| LG-PL-7/8 | 7/8” | 5.25 | 1.75 | 3.5 | 2.78 | 14000 |
| LG-PL-1 | 1” | 6 | 2 | 4 | 4.3 | 24360 |
| LG-PL-1-1/4 | 1-1/4” | 7.75 | 2.5 | 5 | 8.5 | 36000 |
| LG-PL-1-3/8 | 1-3/8” | 8.25 | 2.75 | 5.5 | 11.5 | 43000 |
| LG-PL-1-1/2 | 1-1/2” | 9 | 3 | 6 | 15.25 | 54300 |
| LG-PL-1-3/4 | 1-3/4” | 10.5 | 3.5 | 7 | 22.5 | 84900 |
| LG-PL-2 | 2” | 12 | 4 | 8 | 34 | 102600 |
