DIN 766 Calibrated Anchor Chain Stainless Steel-China LG™

Description

Introducing the China LG™ DIN 766 Calibrated Stainless Steel Anchor Chain:

The China LG™ DIN 766 Calibrated Stainless Steel Anchor Chain is designed for anchor rodes on small boats when paired with 8mm or 10mm anchor rope. Crafted from AISI 316 stainless steel, this anchor chain is produced on automatic chain making machines to ensure top quality. Each chain is calibrated during manufacturing and undergoes proof load testing at the conclusion of the process to guarantee reliability and performance. Available in a range of sizes from 5mm to 13mm, this anchor chain offers versatility to suit various needs and preferences.

Presenting the DIN 766 Calibrated Stainless Steel Anchor Chain:

The DIN 766 Calibrated Stainless Steel Anchor Chain is a top-quality chain designed for use in anchor rodes on small boats, particularly when paired with 8mm or 10mm anchor rope. Crafted from AISI 316 stainless steel, this chain is manufactured using automatic chain making machines to ensure precision and durability. Each chain is calibrated during production and subjected to proof load testing at the end of the manufacturing process to ensure its strength and reliability. With sizes ranging from 5mm to 13mm, this anchor chain offers a versatile solution for various marine applications. Trust in the DIN 766 Calibrated Stainless Steel Anchor Chain for secure and reliable anchoring on your vessel.

Technical & Feature



Technical Notes	To DIN 766
Material	Stainless Steel(AISI 304 / AISI 316)
Processing	Welded + Deburring
Finish	High Polishing / Electrophoretic Coating
Size	5mm , 6mm , 7mm , 8mm , 9mm , 10mm , 11mm , 12mm , 13mm
Note	NOT FOR OVERLOAD LIFTING
Brand	LG™
Origin	China



Specification-DIN 766 Calibrated Anchor Chain Stainless Steel

Part No.	SIZE		INSIDE LENGTH			INSIDE WIDTH	OUTSIDE WIDTH	LENGTH PER 11LINKS			WEIGHT PER M
	MM	+/-MM	MM	+MM	-MM	MM	MM	MM	+MM	-MM	KG
LG-SS-766-C-05	5	0.2	18.5	0.4	0.2	6	17	203.5	2.4	1.2	0.5
LG-SS-766-C-06	6	0.2	18.5	0.4	0.2	7.2	20.2	203.5	2.4	1.2	0.8
LG-SS-766-C-07	7	0.3	22	0.4	0.2	8.4	23.8	242	3	1.4	1.1
LG-SS-766-C-08	8	0.3	24	0.4	0.2	9.6	27.2	264	3.2	1.5	1.4
LG-SS-766-C-09	9	0.4	27	0.5	0.3	10.8	30.6	297	3.6	1.8	1.8
LG-SS-766-C-10	10	0.4	28	0.5	0.3	12	34	308	3.7	1.9	2.2
LG-SS-766-C-11	11	0.4	31	0.5	0.3	13.2	37.4	341	4	2	2.7
LG-SS-766-C-12	12	0.3	36	0.6	0.3	14.4	40.8	396	4.4	2.2	3.1
LG-SS-766-C-13	13	0.5	36	0.6	0.3	15.6	44.2	396	4.6	2.4	3.8
